7-46 PQM Power Quality Meter GE Power Management
7.3 MODBUS MEMORY MAP 7 MODBUS COMMUNICATIONS
7
SWITCH D
continued
10EC Switch D Time Delay 0 to 6000 1 0.1 x s F1 0.0 s
10ED Reserved
10EE Reserved
10EF Reserved
PULSE
OUTPUT
10F0 Positive kWh Pulse Output Relay 0 to 4 1 --- F29 0=OFF
10F1 Positive kWh Pulse Output Interval 1 to 65000 1 kWh F1 100 kWh
10F2 Negative kWh Pulse Output Relay 0 to 4 1 --- F29 0=OFF
10F3 Negative kWh Pulse Output Interval 1 to 65000 1 kWh F1 100 kWh
10F4 Positive kvarh Pulse Output Relay 0 to 3 1 --- F29 0=OFF
10F5 Positive kvarh Pulse Output Interval 1 to 65000 1 kvarh F1 100 kvarh
10F6 Negative kvarh Pulse Output Relay 0 to 3 1 --- F29 0=OFF
10F7 Negative kvarh Pulse Output Interval 1 to 65000 1 kvarh F1 100 kvarh
10F8 kVAh Pulse Output Relay 0 to 3 1 --- F19 0=OFF
10F9 kVAh Pulse Output Interval 1 to 65000 1 kVAh F1 100 kVAh
10FA Pulse Output Width 100 to 2000 10 ms F1 100 ms
10FB Serial Pulse Relay Interval 100 to 10000 100 ms F1 100 ms
10FC Reserved
PULSE
INPUT
10FD Pulse Input Units 1
st
and 2
nd
char. --- --- ASCII F10 “ U”
10FE Pulse Input Units 3
rd
and 4
th
char. --- --- ASCII F10 “ni”
10FF Pulse Input Units 5
th
and 6
th
char. --- --- ASCII F10 “ts”
1100 Pulse Input Units 7
th
and 8
th
char. --- --- ASCII F10 ““
1101 Pulse Input Units 9
th
and 10
th
char. --- --- ASCII F10 ““
1102 Pulse Input 1 Value 0 to 65000 1 Units F1 1
1103 Pulse Input 2 Value 0 to 65000 1 Units F1 1
1104 Pulse Input 3 Value 0 to 65000 1 Units F1 1
1105 Pulse Input 4 Value 0 to 65000 1 Units F1 1
1106 Pulse Input Total 0 to 10 1 --- F43 9 = 1+2+3+4
1107 Reserved
ALARM
RELAY
1108 Alarm Relay Operation 0 to 1 1 --- F17 0 = NON-FAILSAFE
1109 Alarm Relay Activation 0 to 1 1 --- F18 0 = UNLATCHED
110A Reserved
to
↓ ↓ ↓ ↓ ↓ ↓
110F Reserved
AUXILIARY
RELAY 1
1110 Auxiliary Relay 1 Operation 0 to 1 1 --- F17 0 = NON-FAILSAFE
1111 Auxiliary Relay 1 Activation 0 to 1 1 --- F18 0 = UNLATCHED
1112 Reserved
to
↓ ↓ ↓ ↓ ↓ ↓
1117 Reserved
AUXILIARY
RELAY 2
1118 Auxiliary Relay 2 Operation 0 to 1 1 --- F17 0 = NON-FAILSAFE
1119 Auxiliary Relay 2 Activation 0 to 1 1 --- F18 0 = UNLATCHED
111A Reserved
to
↓ ↓ ↓ ↓ ↓ ↓
111F Reserved
Table 7–10: PQM MEMORY MAP (Sheet 32 of 40)
GROUP ADDR
(HEX)
DESCRIPTION RANGE STEP
VALUE
UNITS and
SCALE
FORMAT FACTORY DEFAULT
Notes: * Data type depends on the Command Operation Code. ** Any valid Actual Values or Setpoints address.
*** Maximum Setpoint value represents “OFF”. **** Minimum Setpoint value represents “OFF”.
***** Maximum Setpoint value represents “UNLIMITED”.
