4-12 PQM Power Quality Meter GE Power Management
4.2 S1 PQM SETUP 4 PROGRAMMING
4
•
CLEAR ALL DEMAND VALUES:
Enter
YES
to clear all the power and current demand data under the
actual values subgroup
A1 METERING \ DEMAND
. The time and date associated with each message will be
updated to the current date upon issuing this command.
•
CLEAR MIN/MAX CURRENT VALUES:
Enter
YES
to clear all the min./max current data under the actual
values subgroup
A1 METERING \ CURRENT
. The time and date associated with each message will be
updated to the current date upon issuing this command.
•
CLEAR MIN/MAX VOLTAGE VALUES:
Enter
YES
to clear all the min./max voltage data under the actual
values subgroup
A1 METERING \ VOLTAGE
. The time and date associated with each message will be updated
to the current date upon issuing this command.
•
CLEAR MIN/MAX POWER VALUES:
Enter
YES
to clear all the min./max power data under the actual val-
ues subgroup
A1 METERING \ POWER
. The time and date associated with each message will be updated to
the current date upon issuing this command.
•
CLEAR MIN/MAX FREQUENCY VALUES:
Enter
YES
to clear all the min./max frequency data under the
actual values subgroup
A1 METERING \ FREQUENCY
. The time and date associated with each message will
be updated to the current date upon issuing this command.
•
CLEAR MAX THD VALUES:
Enter
YES
to clear all the max THD data under the actual values subgroup
A3 POWER ANALYSIS \ TOTAL HARMONIC DISTORTION
. The time and date associated with each message will
be updated to the current date upon issuing this command.
•
CLEAR PULSE INPUT VALUES:
Enter
YES
to clear all the pulse input values under the actual values sub-
group
A1 METERING \ PULSE INPUT
. The time and date associated with this message will be updated to the
current date upon issuing this command.
•
CLEAR EVENT RECORD:
Enter
YES
to clear all of the events in the Event Record. This will eliminate all
previous events from the Event Record and create a CLEAR EVENTS event as the new event number 1.
The Event Recorder can be cleared only if it is enabled in
S1 PQM SETUP \ EVENT RECORDER \
EVENT RECORDER OPERATION
.
•
LOAD FACTORY DEFAULT SETPOINTS:
When the PQM is shipped from the factory all setpoints will be
set to factory default values. These settings are shown in the setpoint message reference figures. To return
a PQM to these known setpoints select
YES
and press the key while this message is displayed.
The display will then warn that all setpoints will be lost and will ask whether to continue. Select yes again to
reload the setpoints. It is a good idea to first load factory defaults when replacing a PQM to ensure all the
settings are defaulted to reasonable values.
