4-32 PQM Power Quality Meter GE Power Management
4.3 S2 SYSTEM SETUP 4 PROGRAMMING
4
•
PULSE INPUT 1 VALUE:
Enter a value in this setpoint that will be equivalent to 1 pulse input on the switch
input assigned to PULSE INPUT 1 (i.e. 1 pulse = 100 kWh). The accumulated value is displayed in actual
values under
A1 METERING\PULSE INPUT COUNTERS\PULSE INPUT 1
.
•
PULSE INPUT 2 VALUE:
Enter a value in this setpoint that will be equivalent to 1 pulse input on the switch
input assigned to PULSE INPUT 2 (i.e. 1 pulse = 100 kWh). The accumulated value is displayed in actual
values under
A1 METERING\PULSE INPUT COUNTERS\PULSE INPUT 2
.
•
PULSE INPUT 3 VALUE:
Enter a value in this setpoint that will be equivalent to 1 pulse input on the switch
input assigned to PULSE INPUT 3 (i.e. 1 pulse = 100 kWh). The accumulated value is displayed in actual
values under
A1 METERING\PULSE INPUT COUNTERS\PULSE INPUT 3
.
•
PULSE INPUT 4 VALUE:
Enter a value in this setpoint that will be equivalent to 1 pulse input on the switch
input assigned to PULSE INPUT 4 (i.e. 1 pulse = 100 kWh). The accumulated value is displayed in actual
values under
A1 METERING\PULSE INPUT COUNTERS\PULSE INPUT 4
.
•
PULSE INPUT TOTAL:
This setpoint allows the user to define which pulse inputs are to added together.
For example, if the selection is this setpoint is
1+2+3
, the PULSE INPUT 1, PULSE INPUT 2 and PULSE
INPUT 3 values shown in
A1 METERING \ PULSE COUNTERS \ PULSE INPUT 1/2/3/4
will be added together and
displayed in
A1:METERING \ PULSE INPUT COUNTERS \ PULSE IN 1+2+3
.
