om 5184516-100 Rev. 5 7-3
1-2Identification and Compliance Plates
See ILLUSTRATION 7-2 and TABLE 7-1.
TABLE 7-1
PRECISION 500D SYSTEM IDENTIFICATION AND COMPLIANCE PLATES
Item Component Model Number Plate Type
1
Suspension X–Ray MX 100 X–Ray Tube Casing 46-155400G46 Identification
Maxiray 100–18 H.S.; Focal Spots 0.6–1.25°, 12.5° 46–155400G2 Identification
X-ray Tube Conformance Label 46–155400G281 Identification, HHS, CE, UL, CSA
Overhead tube Collimator AL01C
2266999
AL01C II
5234954
Identification, CSA, UL, HHS (On colli-
mator inside Tube assembly)
Maxiray 100–18 H.S.; Focal Spots 0.3 – 1.0; 12.5° 46–155400G290 Identification, HHS, CE, UL, CSA
2 Image Intensifier (40 cm/16 Inch) Digital 2289147 Identification, HHS, CSA
Image Intensifier (32 cm/12 Inch) Digital 2289148 Identification, HHS, CSA
3 Intelligent Digital Device 2403790-3 Identification
4
Precision 500D R&F Table 2403791-3 Identification, HHS, CE Label, CSA
Precision 500D R&F Table Collimator (Undertable) AF01A
2292592
AF01A II
5234960
Identification, HHS, CSA, CE, UL (On
collimator inside table)
Precision 500D Table Fluoro MX–100 X–Ray Tube
Casing (Adjusted with 2.1° wedge)
46–155500G18 Identification
Maxiray 100FL; Focal Spots 0.6 – 1.0; 12.5 (Fluoro) 46-155318G36 Identification
X-ray Tube Conformance Label 46–155500G228 Identification, HHS, CE, UL, CSA (On
tube inside table)
Precision 500D Table Reciprocating Bucky 2189554 Identification (On bucky inside table)
Precision 500D Table Cassette Size Sensing Tray 2176788 Identification (On bucky CSS tray
inside table)
5 Precision 500D Table Top 46–180600G4 Identification, HHS
6
Operator Console (X-ray control if manufactured on
or after Aug 17, 2007)
5117866-27 Identification
5261130
5272650
Identification, HHS
7 Precision 500D Positioner Cabinet 2401181 Identification, CSA, CE
8
System Cabinet 5176501
5224631
Identification, CSA, CE
JEDI Generator 65 kW, 80 kW (X-ray control if manu-
factured before Aug 17, 2007)
2290800 Identification, HHS, CSA, CE, IEC
(Also on X-ray Generator inside cabi-
net)
Digital Imaging System
2407276-2 Identification, CSA, UL (On Digital
Imaging system inside cabinet)
5174991 Identification (On digital Imaging sys-
tem inside cabinet)
FOR TRAINING PURPOSES ONLY!
NOTE: Once downloaded, this document is UNCONTROLLED, and therefore may not be the latest revision. Always confirm revision status against a validated source (ie CDL).
