Several features are controlled via the Image Monitor. Each Monitor screen is
divided into two areas: the left side is dedicated to image selection and features
controls, and the right side shows the image display and a few feature controls
(see ILLUSTRATION 3-1).
• Sometimes menus are shown over the image portion of the screen. The sys-
tem operation is designed such that these menus do not usually interfere with
the normal image viewing.
ILLUSTRATION 3-1I
ACQUIRE GENERAL SCREEN
