7-22 VersaMax® Modules, Power Supplies, and Carriers User's Manual – March 2003 GFK-1504K
7
IC200MDL243
Input Module, 120VAC Isolated 16 Points
Module Specifications
Module Characteristics
Points 16 Isolated Inputs
Module ID 88048804
Isolation:
User input to logic (optical)
and frame ground
Group to group
Point to point
250VAC continuous; 1500VAC for 1 minute
Not applicable
250VAC continuous; 1500VAC for 1 minute
LED indicators One LED per point shows individual point ON/OFF status
OK LED indicates backplane power is present
Backplane current
consumption
5V output: 100mA maximum
External power supply None
Thermal derating See diagram
Input Characteristics
Input voltage 0 to 132VAC (47 to 63Hz), 120VAC nominal
On state voltage
Off state voltage
70 to 132VAC
0 to 20VAC
On state current
Off state current
5mA minimum
2.5mA maximum
On response time
Off response time
1 cycle maximum
2 cycles maximum
Input impedance 8.6kOhms (reactive) at 60Hz, typical
10.32kOhms (reactive) at 50Hz, typical
