7-36 VersaMax® Modules, Power Supplies, and Carriers User's Manual – March 2003 GFK-1504K
7
IC200MDL635
Input Module, 48VDC Pos/Neg Logic Grouped 16 Points
Module Specifications
Module Characteristics
Points 16 inputs (2 groups of 8)
Module ID FFFF8008
Isolation:
User input to logic (optical)
and to frame ground
Group to Group
Point to point
250VAC continuous; 1500VAC for 1 minute
250VAC continuous; 1500VAC for 1 minute
None
LED indicators One LED per point shows individual point ON/OFF status
OK LED indicates backplane power is present
Backplane current
consumption
5V output: 70 mA maximum
External power supply None
Thermal derating No derating
Configuration parameters Input response times
Input Characteristics
Input voltage 0 to 60VDC, 48 VDC nominal
User input current 1.7mA typ. @ 48VDC, 2.1mA typ. @ 60VDC
Input impedance 28K Ohm typ.
On state voltage 34VDC to 60VDC
Off state voltage 0 VDC to 10DC
On state current
Off state current
1.0mA minimum
0 to 0.4mA maximum
On response time
Off response time
0.5ms maximum
Configurable filter time 0ms, 1.0ms (default), or 7.0ms
