GFK-1504K Chapter 9 Discrete Mixed Modules 9-45
9
IC200MDD850
Mixed Module, Output Relay 2.0A per Pt Isolated 8 Points /
Input 240VAC Isolated 4 Points
Module Specifications
Module Characteristics
Points 8 Individually-isolated Form A Relay Outputs
4 Isolated AC Inputs
Module ID 88028040
Isolation:
User input/output to logic
(optical) and frame ground
Group to group
Point to point
250VAC continuous; 1500VAC for 1 minute
250VAC continuous; 1500VAC for 1 minute
Outputs: 250VAC continuous; 1500VAC for 1 minute
Inputs: 250VAC continuous; 1500VAC for 1 minute
LED indicators One LED per point shows individual point on/off state
OK LED indicates backplane power is present
Backplane current consumption
5V output: 275mA maximum See graph
Thermal derating None
Input Characteristics
Input voltage 0 to 264VAC (47 to 63Hz), 240VAC nominal
On state voltage 155 to 264VAC
Off state voltage 0 to 40VAC
On state current
Off state current
4mA minimum
1.5mA maximum
On response time
Off response time
1 cycle maximum
2 cycles maximum
Input impedance 38.5kOhms (reactive) at 60Hz, typical
46.3kOhms (reactive) at 50Hz, typical
Output Characteristics
Output voltage 0 to 125VDC, 5/24/125VDC nominal
0 to 265VAC (47 to 63Hz), 120/240VAC nominal
Output voltage drop 0.3V maximum
Load current 10mA per point minimum
2.0 Amps for 5 to 265VAC maximum (resistive)
2.0 Amps for 5 to 30 VDC maximum (resistive)
0.2 Amp for 31 to 125 VDC maximum (resistive)
Output leakage current Not applicable (open contact)
On response time
Off response time
10ms maximum
10ms maximum
Protection No internal fuses or snubbers.
Switching frequency 20 cycles per minute (inductive load)
Relay type Fixed coil, moving armature
Contact type Silver alloy
Contact life See appendix B
