GFK-1504K Chapter 10 Analog Input Modules 10-37
10
IC200ALG263
Analog Input Module, 15 Bit Voltage 15 Channels
Module Specifications
Module Characteristics
Channels 15 single ended, one group
Module ID FFFFB00F
Isolation:
User input to logic (optical) and to
frame ground
Group to group
Channel to channel
250VAC continuous; 1500VAC for 1 minute
Not applicable
None
LED indicators OK LED. See "LED Indicators" for description.
Backplane current consumption 5V output: 150mA maximum
External power supply None
Thermal derating None
Configuration parameters None
Diagnostics Loss of Internal Power
A/D conversion malfunction greater than 6% of full scale
Input Characteristics
Input voltage -10V to +10V
Input Impedance 100K Ohms minimum
Accuracy at:
25 degrees C*
0 to 60 degrees C
+/-0.3% typical of full scale, +/-0.5% maximum of full scale
+/-1% maximum of full scale
Resolution +/- 15 bits
0.3125mV = 1 count
Filter response (3dB Corner Freq) 32 Hz +/-20%
Update rate per module 7.5ms
Compatibility
VersaPro Software Version 2.0 or higher
VersaMax PLC CPU Firmware Version 2.10 or higher
VersaMax Ethernet NIU Firmware Version 1.10 or higher
VersaMax DeviceNet, Profibus, or
Genius NIU Firmware
Planned for future release
*
In the presence of severe RF interference, (IEC 1000-4-3, 10V/m), accuracy may be degraded to +/-2%.
