GFK-1504K Chapter 10 Analog Input Modules 10-43
10
IC200ALG264
Analog Input Module, 15 Bit Current 15 Channels
Module Specifications
Module Characteristics
Channels 15 single ended, one group
Module ID FFFFB50F (when cfg for 4-20mA range)
FFFFB40F (when cfg for 0-20mA range)
Isolation:
User input to logic (optical) and to
frame ground
Group to group
Channel to channel
250VAC continuous; 1500VAC for 1 minute
Not applicable
None
LED indicators OK LED. See "LED Indicators" for description.
Backplane current consumption 5V output: 100mA maximum
External power supply None
Thermal derating None
Configuration parameters Range select (jumpers on carrier)
Diagnostics Loss of Internal Power, Open wire detection of 4-20mA
signals only
Input Characteristics
Input current 4 to 20mA (default : no terminal jumper installed)
0 to 20mA (with terminal jumper installed)
Input Impedance 100 Ohms
Accuracy at:
25 degrees C*
0 to 60 degrees C
( See Notes 1, 2, & 3 )
+/-0.3% typical of full scale, +/-0.5% maximum of full
scale
+/-1% maximum of full scale
Resolution 15 bits
0.5
µ
A = 1 counts (for 4-20mA range)
0.625
µ
A = 1 counts (for 0-20mA range)
Filter response (3dB Corner Freq) 24 Hz +/-20%
Update rate per module 7.5ms
Compatibility
VersaPro Software Version 2.0 or higher
VersaMax PLC CPU Firmware Version 2.10 or higher
VersaMax Ethernet NIU Firmware Version 1.10 or higher
VersaMax DeviceNet, Profibus, or
Genius NIU Firmware
Planned for future release
*
In the presence of severe RF interference, (IEC 1000-4-3, 10V/m), accuracy may be degraded to +/-2%.
