IRECTION FQ091019, REVISION 2 VIVID Q N SERVICE MANUAL
Chapter 5 - Components and Function (Theory) 5-9
5-3-2 Front End Unit - Location in the System
The Front End unit is located in the Bottom assembly, on the right side, as shown in Figure 5-5.
Figure 5-5 Bottom Assembly showing Location of Front End
Figure 5-6 Keyboard Assembly in Opened Position
WARNINGWARNING
When opening and closing the Keyboard Assembly, take care not to damage the cables
connected to the BEP (indicated in Figure 5-6, above).
BEP
RS Probe Connector
Power Supply
Front End
BEP Cables
Keyboard
Assembly
ECG Cable
ECG Module
