GE
D
IRECTION FQ091019, REVISION 2 VIVID Q N SERVICE MANUAL
5-10 Section 5-3 - Front End Unit
Figure 5-7 Bottom Assembly showing Position of Boards (RFI,TR32, P&M)
Probe and MUX Board
TR32 Boards
(located below
the RFI Board)
RFI Board
