GE
D
IRECTION FQ091019, REVISION 2 VIVID Q N SERVICE MANUAL
Chapter 5 - Components and Function (Theory) 5-23
For reference, a list of abbreviations used in this section is provided in Table 5-8 below.
5-4-2 ETX SBC Central Processing Unit (CPU)
The ETX SBC Central Processing Unit (CPU), which is mounted on top of the ETX Base Board (see
page 5 - 23), controls and processes the internal Back End Processor operations. In addition, the CPU
supports the Front End via the PCI bus.
The CPU utilized in the Vivid q N ultrasound unit is a Pentium -M, 1.4 GHz Processor.
5-4-3 ETX Base Board
5-4-3-1 Overview of ETX Base Board Functions
The ETX Base Board connects all the peripheral modules to the ETX single board computer. The CPU
(see page 5 - 23) is mounted on top of the ETX Base Board.
The ETX Base Board provides interfaces to the following components:
•HDD
• Front End (RFI) Board
• USB ports
• Docking port, speaker phones and speaker jacks
• Keyboard
• Battery
•VGA
•Fans
• Power supply
The Power Management Controller (PMC), mounted on the ETX Base Board, ensures automatic
transition between the various power modes, stable DC condition, and provides power status LED display.
The Docking port, located on the rear panel of the ETX Base Board, provides the connections to the
Audio unit on the DIB, discrete control and status lines and 20V-DC power.
Refer to Figure 5-21 on page 5-27 for a view of the ETX Base Board showing the location of the various
connectors.
Table 5-8 Abbreviations and Definitions
Abbreviation Definition
BGA Ball Grid Array
CS Component Side
EMC Electro Magnetic Compatibility
FPGA Field Programmable Gate Array
HDD Hard disk drive
MTBF Mean Time Between Failures
PCI Peripheral Card Interconnect
PLD Programmable Logic Device
P&M Probe and MUX Board
PMC Power Management Controller
PS Power Supply
