GE
D
IRECTION FQ091019, REVISION 2 VIVID Q N SERVICE MANUAL
Chapter 6 - Service Adjustments 6-9
6-1-3 Keyboard Adjustments
6-1-3-1 Backlighting Intensity Adjustment Procedure
To make adjustments to the Keyboard Backlighting intensity, follow the procedure described in "Adjust
Keyboard Backlight Intensity" on page 3-76.
6-1-4 Configuring Print Orientation
For information on Print Orientation (Portrait or Landscape), refer to "Configuring Printing Orientation
(Portrait or Landscape) and Paper Size" on page 3-23.
6-1-5 Video System Adjustments
6-1-5-1 Video System Adjustment Procedure
For details on Video System adjustments (PAL or NTSC setup), refer to Figure 3-46 on page 3-49.
6-1-6 Beamformer Calibration
6-1-6-1 Beamformer Calibration Procedure
For details on Beamformer Calibration adjustments, refer to Chapter 7 - Diagnostics/Troubleshooting.
