Geely CK MR479QA 2007 User Manual

153
4. Remove the rear brake hose compo.
Loose the union thread that connects the rear brake hose to LR and RR brake pipe compo., remove the
E-shaped clip on the hose support bracket. Remove the rear brake hose compo.
5. Remove rear left, right brake pipe compo.
(1) Remove a dual tube clip
(2) Remove three 5-pipe clips
(3) Remove rear left, right brake pipe compo.
6. Remove front brake hose assembly
(1) Loose the union thread that connects the front brake hose to LR and RR brake pipe
(2) Remove E-shaped clip on the hose bracket
(3) Loose the union thread that connects the front brake hose to the front brake. Remove the front
brake hose assembly from the front brake
7. Remove the front left, front right brake pipe compo.
8. Remove the No. 1 & 2 brake pipe compo. which connect the brake master cylinder to HECU controller
