106 ADV200 • Quick start up guide
log inp 1 type parameter (14 - ANALOG INPUTS menu, PAR.1502):
0 ± 10V
1 0-20mA o 0-10V
2 4-20mA
As well as programming the Analog inp 1 type parameter (PAR:1502) you must
also verify the position of the switches on the regulation card, as showed on
chapter 5.2.4.
• Ramps setting
The acceleration and deceleration ramps can be set in Acceleration time 0 (06 -
RAMPS menu, PAR: 700) and Deceleration time 0 (PAR: 702).
The signal available on the analog input can be adjusted using Analog inp 1
scale parameter (14 - ANALOG INPUTS menu, PAR: 1504), An inp 1 offset
tune parameter (PAR: 1506) and An inp 1 gain tune parameter (PAR: 1508).
To use a digital speed to control the drive, enter it in the Dig ramp ref 1 parameter
(05 - REFERENCES menu, PAR: 600).
The ramps are the same used with the reference signal from the analog input.
• Multispeed
To use more than one digital speed, use the multi-speed function.
First select the source of the speed signals Multi ref 0 src and Multi ref 1 src (07
- MULTI REFERENCE menu, PAR: 832 e 834) from the L_MLTREF selection list.
Next dene which digital inputs are to perform switching between the various
speeds; use the Multi ref sel .. src parameters (PAR: from 840 to 846) to select
the signals to use from the L_DIGSEL2 selection list. Set the desired speeds in
the Multi reference 0...7 parameters (PAR: from 800 to 814).
Also in this case the ramps can be set in the Acceleration time 0 parameter
(06 - RAMPS menu, PAR: 700) and Deceleration time 0 parameter (PAR: 702)
parameters.
• Motor potentiometer
To use the motor potentiometer, the signals to increase or decrease the reference
must be dened: set the Mpot up src parameter (08 - MOTOPOTENTIOMETER
menu, PAR: 884) and Mpot down src parameter (PAR: 886) parameters respec-
tively to increase and decrease the reference using selection list L_DIGSEL2.
Set the motor potentiometer ramps using Mpot acceleration (PAR: 872) and
Mpot deceleration parameters (PAR: 874).
• Jog
Finally, for Jog mode, select the control terminal in the Jog cmd + src parameter
(09 - JOG FUNCTION menu, PAR: 916), using a signal from selection list L_DIG-
SEL2.
The Jog speed must be written in the Jog setpoint parameter (PAR: 910), while
the acceleration and deceleration ramps can be set, respectively, in Jog accelera-
tion (PAR: 912) and Jog deceleration parameters (PAR: 914).
• Speed limits
After selecting the reference, set the speed limits in the following parameters (05 -
REFERENCES menu):
- Full scale speed (PAR: 680). Setting of the maximum motor speed, which
usually coincides with the rated speed indicated on the motor data plate.
