172 ADV200 • Quick start up guide
Grid: 460V / 60Hz - Motor voltage: 460V
Motor Power
4 poles IE2
Motor
Efficiency
Drive Size
Drive Output: Light Duty
RHF Passive Filter
Line
Input Current
@ 380V
Rated
Power
Rated
Current
Overload
Type (1) Current
[%] [kW] [A] [A] [A]
710 96.5 630 kW 710 1107 On request
800 96.7 710 kW 800 1242 On request
1000 96.7 900 kW 1000 1620 (2) On request
1200 96.7 1 MW 1200 1845 On request
1500 96.7 1.35 MW 1650 2286 On request
1800 96.7 1.65 MW 1800 2790 On request
(1) RHF-A/B: RHF-A Models ... or RHF-B-... , RHF-AS/BS: RHF-AS Models ... or RHF-BS-...; see section 10.4.1.
(2) Overload 110% the Rated Current for 60s every 300s
(3) Reduced THDi performance due to part load
10.4.4 Dimensions and weights of RHF lters
RHF Passive Filter (4) Q.ty * Frame Dimensions: H * W *d (mm) Weight (kg)
RHF-A/B 6-400-50-20-A
RHF-A/B 10-400-50-20-A X1 347 * 190 * 206 18
RHF-A/B 14-400-50-20-A X2 451 * 232 * 248 20
RHF-A/B 22-400-50-20-A X2 451 * 232 * 248 30
RHF-A/B 29-400-50-20-A X3 605 * 378 * 242 52
RHF-A/B 35-400-50-20-A X3 605 * 378 * 242 53
RHF-A/B 43-400-50-20-A X3 605 * 378 * 242 58
RHF-A/B 58-400-50-20-A X4 634 * 378 * 333 76
RHF-A/B 72-400-50-20-A X4 634 * 378 * 333 98
RHF-A/B 86-400-50-20-A X5 747 * 418 * 333 104
RHF-A/B 144-400-50-20-A X6 778 * 418 * 400 126
RHF-A/B 180-400-50-20-A X6 778 * 418 * 400 135
RHF-A/B 217-400-50-20-A X7 911 * 468 * 449 172
RHF-A 252-400-50-20-A X7 911 * 468 * 449 136
RHF-B 252-400-50-20-A X7 911 * 468 * 449 206
RHF-A 325-400-50-20-A X7 911 * 468 * 449 147
RHF-B 325-400-50-20-A X8 911 * 468 * 540 230
RHF-A 380-400-50-20-A X7 911 * 468 * 449 172
RHF-B 380-400-50-20-A X8 911 * 468 * 540 265
RHF-A 433-400-50-20-A X8 911 * 468 * 540 205
RHF-B 433-400-50-20-A X8 911 * 468 * 540 272
RHF-AS/BS 480-400-50-230-A X38 951 * 211 * 431
RHF-AS/BS 550-400-50-230-A X38B 951 * 307 * 444,5
RHF-AS/BS 600-400-50-230-A 2 * X38 951 * 211 * 431
RHF-AS/BS 650-400-50-230-A 2 * X38 951 * 211 * 431
RHF-AS/BS 750-400-50-230-A 2 * X38 951 * 211 * 431
RHF-AS/BS 850-400-50-230-A 2 * X38B 951 * 307 * 444,5
RHF-AS/BS 980-400-50-230-A 2 * X38B 951 * 307 * 444,5
RHF-AS/BS 1090-400-50-230-A 2 * X38B 951 * 307 * 444,5
RHF-AS/BS 1200-400-50-230-A 3 * X38B 951 * 307 * 444,5
(4) RHF-A/B: RHF-A Models ... or RHF-B-... , RHF-AS/BS: RHF-AS Models ... or RHF-BS-...
