ADV200 • Quick start up guide 113
7.3.4 Multiple destination
Several functions can be assigned together to each input: to display which and
how many functions have been assigned to each input, check the relative “dest”
parameter to see whether there is a number shown in square brackets to the right
of the number of the selected parameter (as shown in the gure below).
T+ T- EN LOC ILim n:0 AL
12.09
PA R: 1156
Digital input3dest
Value: 722 [1]
>> Multi ramp sel0src
If there is a number, press the key to display the next source applied to the se-
lected input.
T+ T- EN LOC ILim n:0 AL
12.09
PA R: 1156
Digital input3dest
Value: 840 [2]
>> Multi ramp sel0src
