gefran ADV200 Series User Manual

ADV200 • Quick start up guide 139
9.7 Output electrical data
U2 Max output voltage ����������������0,94 x U
ln
(U
ln
=AC Input voltage)
f2 Max output frequency ���������������500 Hz (Sizes 1007 ... 72000) , 200 Hz (≥ Size 72500):
see section 9.3.3 for more details.
Braking IGBT Unit �������������������� KBX models: standard internal with external resistor,
KXX: not included;
braking torque 150 % MAX
BR ON/OFF (Programmable through P454) ��@ 400V = Default 670-660Vdc
@ 480V = Default 800-790Vdc
Sizes Inverter Output P
n
mot (Recommended asynchronous motor output)
Heavy duty
(KVA)
Light duty
(KVA)
Heavy duty Light duty
@400 V
ac
(kW)
@460 V
ac
(Hp)
@400 V
ac
(kW)
@460 V
ac
(Hp)
1007 1.7 3.0 0.75 1 1.5 2
1015 3.0 4.0 1.5 2 2.2 3
1022 4.0 5.3 2.2 3 3 5
1030 5.3 6.6 3.0 5 4 5
1040 6.6 9 4.0 5 5.5 7.5
2055 9 11.4 5.5 7.5 7.5 10
2075 11.4 15.9 7.5 10 11 15
2110 15.9 21.5 11 15 15 20
3150 21.5 26.3 15 20 18.5 25
3185 26.3 32 18.5 25 22 30
3220 32 43 22 30 30 40
4300 43 52 30 40 37 50
4370 52 60 37 50 45 60
4450 60 73 45 60 55 75
5550 73 104 55 75 75 100
5750 104 125 75 100 90 125
5900 125 145 90 125 110 150
61100 145 173 110 150 132 175
61320 173 208 132 175 160 200
71600 208 267 160 200 200 250
72000 267 319 200 250 250 300
72500 319 409 250 300 315 400
73150 409 450 315 400 355 450
73551 450 506 355 450 400 500
400 kW 506 603 400 500 500 650
500 kW 603 776 500 650 630 850
630 kW 776 852 630 850 710 950
710 kW 852 956 710 950 800 1100
900 kW 1108 1247 900 1200 1000 1300
1 MW 1247 1420 1000 1300 1200 1600
