gefran ADV200 Series User Manual

26 ADV200 • Quick start up guide
5.1 Power section
5.1.1 Cable Cross Section
Sizes
Terminals: L1 - L2 - L3 - BR1 - BR2 - C - D - U - V - W
Maximum Cable Cross Section (flexible conductor) Recommended stripping Tightening torque (min)
(mm
2
) AWG (mm) (Nm)
1007 4 10 7 0,5 ... 0,6
1015 4 10 7 0,5 ... 0,6
1022 4 10 7 0,5 ... 0,6
1030 4 10 7 0,5 ... 0,6
1040 4 10 7 0,5 ... 0,6
2055 6 8 10 0,7 ... 0,8
2075 6 8 10 1,2 ... 1,5
2110 6 7 12 1,5 ... 1,7
3150 16 6 14 1,5 ... 1,7
3185 16 6 14 1,5 ... 1,7
3220 16 6 14 1,5 ... 1,7
4300 35 2 18 2,4 ... 4,5
4370 35 2 18 2,4 ... 4,5
4450 35 2 18 2,4 ... 4,5
5550 95
(BR1/BR2=50) 4/0 (BR1/BR2=1/0) 23 (BR1/BR2=27) 14 (BR1/BR2=10)
5750 95 4/0 23 14
5900 95 4/0 23 14
61100 150 300 30 24
61320 240 500 40 40
Sizes
Bars: L1 - L2 - L3 - C - D - U - V - W
Recommended cable cross-section Lock screw diameter Tightening torque (min)
(mm
2
) AWG / kcmil (mm) (Nm)
71600 - 72000 2 x 100 2 x AWG 4/0 M10
25
72500 2 x 150 2 x kcmil 300 M10
25
73150 - 73551 2 x 185 2 x kcmil 350 M10
25
Sizes
Connection
on mechanical cabinet
Cable Cross Section Lock screw
diameter
Recommended
terminal
Tightening torque
(mm
2
) AWG / kcmil (mm) (Nm)
1007 ... 1022 16 AWG 6 M5 Eyelet - Spade 5
1030 ... 4450 16 AWG 6 M6 Eyelet - Spade 5
5550 ... 5900 50 AWG 1/0 M6 Eyelet - Spade 5
61100 75 AWG 2/0 M8 Eyelet - Spade 12
61320 120 250 kcmil M8 Eyelet - Spade 12
Connection
on bars
71600 ... 72500 150 300 kcmil M10 Eyelet 25
73150 - 73551 185 350 kcmil M10 Eyelet 25
