ADV200 • Quick start up guide 33
5.1.6 Power line connection
ADV1007 ... ADV61320
L1 L2 L3 BR1 BR2 CDUVW
K1M
L1 L2 L3
F1
( 400 V/460 50/60 Hz)
AC3ph -VAC
,
ADV3185-...-DC ... ADV61320-...-DC
CD
K1M
F1
DC - 450/750 V
DC
ADV71600 ... ADV73551
CD
L1 L2 L3 UVW
K1M
L1 L2 L3
F1
( 400 V/460 50/60 Hz)AC3ph -VAC,
L1
