ADV200 • Quick start up guide 147
9.10 Weight and dimensions
Sizes
ADV200-...-4
Weight (kg) Weight (lbs) Sizes
ADV200-...-4-DC
Weight (kg) Weight (lbs)
1007 ... 1040 5.8 12.8 - - -
2055 ... 2110 10.2 22.5 - - -
3150 ... 3185 16.4 36.2 3185 12 26.5
3220 22 48.5 3220 18 39.7
4300 ... 4450 32 70.6 4300 ... 4450 24 52.9
5550 ... 5900 60 132 5550 ... 5900 40 88.2
61100 ... 61320 90 198 61100 ... 61320 68 150
71600 ... 72000 130 287 71600 ... 72000 120 267
72500 140 309 72500 130 287
73150 ... 73551 150 331 73150 ... 73551 140 307
400 kW 260 573 400 kW 240 529
500 kW 280 617 500 kW 260 573
630 ... 710 kW 450 992 630 ... 710 kW 420 926
900 kW ... 1 MW 450 992 900 kW ... 1 MW 420 926
Note ! Weights referred to standard drive with keypad, without options, packaging not included.
