gefran ADV200 Series User Manual

ADV200 • Quick start up guide 141
Sizes
ADV200-DC
I
n
Rated output current
(For Asynchronous motors)
I
n
Rated output current
(For Synchronous motors)
@540 Vdc
Heavy duty
(A)
@540 Vdc
Light duty
(A)
@650 Vdc
Heavy duty
(A)
@650 Vdc
Light duty
(A)
@540 Vdc
Heavy duty
(A)
@540 Vdc
Light duty
(A)
@650 Vdc
Heavy duty
(A)
@650 Vdc
Light duty
(A)
3185 38 46 34.2 41.4 34 41 30.6 36.9
3220 46 62 41.4 55.8 41 56 36.9 50.4
4300 62 75 55.8 67.5 56 68 50.4 61.2
4370 75 87 67.5 78.3 68 78 61.2 70.2
4450 87 105 78 94,5 78 95 70.2 85.5
5550 105 150 94.5 135 95 135 85.5 121.5
5750 150 180 135 162 135 162 122 146
5900 180 210 162 189 162 189 146 170
61100 210 250 189 225 189 225 170 203
61320 250 300 225 270 225 270 203 243
71600 300 385 270 347 270 347 243 312
72000 385 460 347 414 347 414 312 373
72500 460 590 414 531 414 531 373 469
73150 590 650 531 585 531 585 469 527
73551 650 730 585 657 585 657 527 591
400 kW 730 870 657 783 657 783 591 705
500 kW 870 1120 783 1008 783 1008 705 907
630 kW 1120 1230 1008 1107 1008 1107 907 996
710 kW 1230 1380 1107 1242 1107 1242 996 1118
900 kW 1600 1800 1440 1620 1440 1620 1296 1458
1 MW 1800 2050 1620 1845 1620 1845 1458 1661
9.7.1 Derating factors
The derating factors shown below are applied to the rated DC output by the user.
They are not automatically implemented by the drive.
Output current derating factors
I
drive
= I
n
x K
v
1 x K
t
x K
alt
x K
f
K
v
1
(1)
: Derating factor for mains voltage from 460V
ac
to 480V
ac
and power sup-
ply from AFE200.
K
t
(2)
: Derating factor for 50°C ambient temperature (1 % each °C above 40°C)
K
alt
(3)
: Derating factor for installation at altitudes above 1000 meters a.s.l.. Value
to be applied at each 100 m increase above 1000 m (up to a maximum of
4000 m).
I.e.: Altitude 2000 m, K
alt
= 1.2 *10 = 12% di derating; I
n
derated = 100 -
((12*100)/100) = 88 % I
n
K
f
(4)
: Derating factor for higher switching frequency
If not all of the derating factors are considered, this could result in a drive overtempera-
ture condition.
The specic alarm indicates this condition and normal drive operation is stopped.
