126 ADV200 • Quick start up guide

8.1.2 “ExtIO fault” Alarm

The drive may generate an “ExtIO fault” alarm for a series of reasons. At drive

startup there may be problems with conguration, associated with the EXP-FL-

XCAN-ADV card or parameter settings. During the Cong phase the alarm might

depend on an SDO communication error. During the Control phase the HeartBeat

or NodeGuarding protocol might fail due to an interruption in the communication

with the slave. An Emergency message sent by the slave could generate the

“ExtIO fault” alarm.

Each reason for the alarm can be identied by to the associated subcode.

The table below shows information about the subcodes and how to associate

these with the cause of the alarm, to enable troubleshooting and proper use of the

system.

Subcode Description Remarks

0 0 BusLoss Loss of communication in the Operational state

1..51 1h..35h SDO error Error sending the SDO. See the SDO Configuration Table on appendix to identify the

object with the problem

200 0xC8 CAN error Internal hardware fault; if the problem cannot be solved, replace the regulation card

202 0xCA Config error The number or I/Os in the slave module has changed. Check parameter 5482 External

IO info. Save the parameters to store the current configuraiton.

203 0xCB Lost Mes-

sages

TPDOs coming from the slave too frequently. Check that the slave meets CANopen

specifications for TPDO sending times

204 0xCC Opt IO

installed

An optional internal I/O expansion card has been installed. The EXP-XCAN-ADV card

functions are not available.

255..65535 0xFF..0xFFFF Slave Emer-

gency

Emergency message sent by the slave.

If the alarm is due to an Emergency message sent by the slave, the subcode

contains the error code (Error code low and Error code Hi) of the message, while

4 of the 5 additional bytes in the message are shown by parameter 5486 External

IO Failcode.

Emergency message content:

Byte0 Byte1 Byte2 Byte3 Byte4 Byte5 Byte6 Byte7

Error code Low Error code Hi Error register Info 0 Info 1 Info 2 Info3 Info4

Subcode PAR 5486 External IO Failcode

See the slave manual for information about the meaning of the Emergency mes-

sage.
