62 ADV200 • Quick start up guide
5.6 Typical connection diagrams
EMERGENCY-OFF
EMERGENCY-OFF
K0
K0
S11
Off
S12
Stop
S2
ON / Start
ON / OFF
Start / Stop
K2
K2T
K2T
K2
G1
R11
R14
Drive ok
t = 1 s
K2
K1M
K1M
Mains contactor
L01
L00
70
72
PRC ok (*)
(*): Only for sizes ≥ ADV71600.
Figure 5.6.1: Auxiliary control circuits
