10.4.5 Dimensions and weights of L0-RHF chokes
L0-RHF-AS/BS mais chokes are included in delivery of the RHF-AS/BS module
lters series (RHF-AS/BS = L0 RHF-AS/BS choke + n lters RHF-R).
L0 RHF-AS/BS
External choke
Dimensions: W * H * d (mm) Weight (kg)
L0-RHF-AS 480-400-50-230-A 420 * 370 * 325
L0-RHF-AS 550-400-50-230-A 420 * 370 * 340
L0-RHF-AS 600-400-50-230-A 420 * 370 * 370
L0-RHF-AS 650-400-50-230-A 420 * 370 * 370
L0-RHF-AS 750-400-50-230-A 480 * 420 * 370
L0-RHF-AS 850-400-50-230-A 480 * 420 * 385
L0-RHF-AS 980-400-50-230-A 480 * 420 * 400
L0-RHF-AS 1090-400-50-230-A 480 * 520 * 420
L0-RHF-AS 1200-400-50-230-A 480 * 520 * 420
L0-RHF-BS 480-400-50-230-A 510 * 500 * 400
L0-RHF-BS 550-400-50-230-A 510 * 540 * 400
L0-RHF-BS 600-400-50-230-A 570 * 620 * 360
L0-RHF-BS 650-400-50-230-A 600 * 620 * 370
L0-RHF-BS 750-400-50-230-A 600 * 620 * 385
L0-RHF-BS 850-400-50-230-A 600 * 620 * 400
L0-RHF-BS 980-400-50-230-A 600 * 620 * 420
L0-RHF-BS 1090-400-50-230-A 600 * 640 * 440
L0-RHF-BS 1200-400-50-230-A 600 * 640 * 460
