ADV200 • Quick start up guide 11
2 - Introduction to the product
The new inverter series ADV200 represents an innovative concept in drive tech-
nology, as a result of the constant technological research and of the experience
that the Gefran Group has acquired keeping a constant presence aside that of the
major sector players.
The new range has been engineered and developed to satisfy the real needs of
System Integrators and OEM’s in order to provide them the best innovations and
economical competitiveness in the international markets.
Based on full mechanical modularity and on a powerful, intuitive and “fully open”
programming platform, ADV200 offers absolute integration exibility with high-
end performance in any system architectures of the most advanced automation
environments.
• Modularity
An innovative concept of integrated technology that offers full modularity. Mountable
side by side and with accessories specically dedicated to system solutions, ADV200
has been engineered to make installation easy for any operator, both in existing
systems and in specic machine solutions, always offering a real reduction of required
space in the cabinet and the best manageability.
• Integrated Quality
ADV200 integrates the fundamental devices for an absolute quality level, such as the
DC choke that ensures maximum reliability in any conditions of working and the input
lter that renders the drive in compliance with the EMC normative EN61800-3. Note: the
choke and lter are not present in ADV200-DC models.
• Fast Access
Structured to offer simple and fast management of the product in any situation of instal-
lation and mounting. From the terminal access to the rack assembling of the options,
each operation is quick and easy.
• Smart Connections
Dedicated accessories and fully removable terminals, ensure simple and fast installa-
tion and start-up in compliance with the EMC normative.
• Options
ADV200 manages up to 3 option cards.
• Safety STO Interface (ADV-...-SI models and the master inverter of 400 kW to 1 MW
parallel versions)
Integrated on board as the 4th option or integrated in the INT-P-ADV power card (sizes
≥ 71600 and from “L” HW version), the EXP- SFTy card allows the motor to be disabled
without the use of a safety contactor on the drive output, guaranteeing compliance to
the directive for machine safety EN61800-5-2 SIL3.
• Serial Line
Integrated standard RS485 serial line with Modbus RTU protocol, for peer-to-peer or
multidrop connections (with OPT-RS485-ADV card).
• Back-Up Supply
ADV200 can be supplied through an external +24Vdc supply in order to be kept active
in case of mains input loss, ensuring in this situation the operation of all monitoring
functions, programming and any connected eldbus network.
• Cables shield
OMEGA clamp to grounding 360° of shielded cables.
