ADV200 • Quick start up guide 13
The inverter must be selected according to the rated current of the motor.
The rated output current of the drive must be higher than or equal to the rated cur-
rent of the motor used.
The speed of the three-phase motor is determined by the number of pole pairs and
the frequency (nameplate, data sheet) of the motor concerned.
Operation above the rated frequency and speed of the motor must take into ac-
count the specications given by the manufacturer losses (bearings, unbalance
etc.). This also applies to temperature specications for continuous operation under
20 Hz (poor motor ventilation, not applicable to motors with external ventilation).
2.1.1 Parallel inverters
• Inverters of between 400 kW and 710 kW comprise one master and one
slave.
• Inverters of over 900 kW comprise one master and two slaves.
When placing your order please give the code number of the master and slave
and number of these:
Power code Description (Designation) Power code Description (Designation)
400kW
S9O25M ADV-72000-KXX-4-MS 04 -SI
400kW
S9O25MC ADV-72000-KXX-4- MS 04-DC- SI
S9O25S ADV-72000-XXX-4-SL S9O25SC ADV-72000-XXX-4- SL-DC
500kW
S9O26M ADV-72500-KXX-4-MS 05 -SI
500kW
S9O26MC ADV-72500-KXX-4-MS 05-DC-SI
S9O26S ADV-72500-XXX-4-SL S9O26SC ADV-72500-XXX-4-SL-DC
630kW
S9O27M ADV-73150-KXX-4-MS 06 -SI
630kW
S9O27MC ADV-73150-KXX-4 -MS 06-DC-SI
S9O27S ADV-73150-XXX-4-SL S9O27SC ADV-73150-XXX-4 -SL-DC
710kW
S9O32M ADV-73551-KXX-4-MS 07 -SI
710kW
S9O32MC ADV-73551-KXX-4- MS 07-DC-SI
S9O32S ADV-73551-XXX-4-SL S9O32SC ADV-73551-XXX-4- SL-DC
900kW
S9O27M1 ADV-73150-KXX-4-MS 09 -SI
900kW
S9O27M2 ADV-73150-KXX-4 -MS 09-DC-SI
S9O27S ADV-73150-XXX-4-SL S9O27SC ADV-73150-XXX-4 -SL-DC
S9O27S ADV-73150-XXX-4-SL S9O27SC ADV-73150-XXX-4 -SL-DC
1 MW
S9O32M1 ADV-73551-KXX-4-MS 10-SI
1 MW
S9O32M2 ADV-73551-KXX-4- MS 10-DC-SI
S9O32S ADV-73551-XXX-4-SL S9O32SC ADV-73551-XXX-4- SL-DC
S9O32S ADV-73551-XXX-4-SL S9O32SC ADV-73551-XXX-4- SL-DC
Note! From January 2015, the ADV-73550 drive size has been replaced by the ADV-73551 drive size and its
parallel configurations
Technical data on this manual are valid for both models.
