156 ADV200 • Quick start up guide

10 - Options

10.1 Optional external fuses

10.1.1 AC input side fuses (F1)

The inverter must be fused on the AC Input side.

Use fast fuses only.

Sizes

F1 - AC input side fuses

DC link

capacitors

life time [h]

EUROPE AMERICA

Type Code Type Code

1007 ... 1030 50000

URZ 50 124 06.11

FWP-10A14Fa

S7G49

URZ 50 124 06.11

FWP-10A14Fa

S7G49

1040 - 2055 50000 FWP-20A14F S7G48 FWP-20A14F S7G48

2075 - 2110 50000 FWP-40B S7G52 FWP-40B S7G52

3150 - 3185 50000 FWP-50B S7G53 FWP-50B S7G53

3220 - 4300 50000 S00C+/üf1/80A/690V F4EAF FWP-80B S7G54

4370 50000 S00C+/üf1/100A/690V F4EAG FWP-100B S7G55

4450 50000 S00C+/üf1/125A/690V F4EAJ FWP-150A S7G56

5550 - 5750 50000 S00üf1/80/200A/690V F4G23 FWP-200A S7G58

5900 50000 S1üf1/110/250A/690V F4G28 FWP-250A S7G59

61100 50000 S1üf1/110/315A/690V F4G30 FWP-350A S7G61

61320 50000 S2üf1/110/400A/690V F4G34 FWP-400A S7G62

71600 50000 S2üf1/110/500A/690V F4E30 FWP-500A S7G63

72000 - 72500 50000 S2üf1/110/630A/690V F4E31 FWP-600A S7G65

73150 - 73551 50000 S3üf1/110/800A/690V F4H02 FWP-800A S7813

400 kW

ADV-72000-KXX-4-MS 04

50000

S2üf1/110/630A/690V

F4E31 FWP-600A S7G65

ADV-72000-XXX-4-SL

50000

S2üf1/110/630A/690V

F4E31 FWP-600A S7G65

500 kW

ADV-72500-KXX-4-MS 05

50000 S2üf1/110/630A/690V F4E31 FWP-600A S7G65

ADV-72500-XXX-4-SL

50000 S2üf1/110/630A/690V F4E31 FWP-600A S7G65

630 kW

ADV-73150-KXX-4-MS 06
