ADV200 • Quick start up guide 155
6.5
1257
[49.49]
9.25
13
1209.5 [47.6]
310.5
240.5
170.7
420
420
31
93
155
177.8
(Optional
BARS KIT)
(*)
485 [19.1]
1636.5 [64.4]
1407 [55.4]
416,5
Quote senza protezioni vedere taglia 7
See Size 7 for dimensions without protections.
(*) Protezione in policarbonato trasparente
(*) Protective trasparent policarbonate
332
144
114
84
420
155
6262 626262
420
Figure 9.10.14: Sizes 900 kW - 1 MW dimensions
