30 ADV200 • Quick start up guide
5.1.4 Block diagram power section
ADV1007 ... ADV61320
L1
L2
L3
C
D
BR2 (*)
BR1 (*)
L
DC
U
V
W
R
PRECHARGE
B
RAKING
IGBT (
OPT
.)
ADV3185-...-DC ... ADV61320-...-DC
C
D
U
V
W
C
DC LINK
450 - 750 Vdc
ADV71600 ... ADV73551
L1
L2
L3
C
D
U
V
W
400 ... 710kW
L1
L2
L3
C
D
U
V
W
ADV- ...- MS..
L1
L2
L3
C
D
U
V
W
LINE
380-500Vac, 3ph
Input
fuse
Input choke
(mandatory)
Input
fuse
Input choke
(mandatory)
ADV- ...- SL..
Output choke
(mandatory)
Output choke
(mandatory)
U
V
W
To motor
