gefran ADV200 Series User Manual

ADV200 • Quick start up guide 31
400 ... 710kW (ADV200-...-DC)
C
D
U
V
W
ADV- ...- MS..-4-DC
C
D
U
V
W
450 - 750 Vdc
Input
fuse
Input
fuse
ADV- ...- SL..-4-DC
Output choke
(mandatory)
Output choke
(mandatory)
U
V
W
To motor
900 kW ... 1 MW
L1
L2
L3
C
D
U
V
W
ADV- ...- MS..
L1
L2
L3
C
D
U
V
W
LINE
380-500Vac, 3ph
Input
fuse
Input choke
(mandatory)
Input
fuse
Input choke
(mandatory)
ADV- ...- SL..
Output choke
(mandatory)
Output choke
(mandatory)
U
V
W
To motor
L1
L2
L3
C
D
U
V
W
Input
fuse
Input choke
(mandatory)
ADV- ...- SL..
Output choke
(mandatory)
900 kW ... 1 MW (ADV200-...-DC)
C
D
U
V
W
ADV- ...- MS..-4-DC
C
D
U
V
W
Input
fuse
Input
fuse
ADV- ...- SL..-4-DC
Output choke
(mandatory)
Output choke
(mandatory)
U
V
W
To motor
C
D
U
V
W
Input
fuse
ADV- ...- SL..-4-DC
Output choke
(mandatory)
450 - 750 Vdc
(*) Terminals BR1/BR2 are standard up to size ADV3220, optional in sizes ADV4300 ... 5550, larger sizes
are not used. These are not present in ADV200-...-DC versions.
