gefran ADV200 Series User Manual

142 ADV200 • Quick start up guide
Sizes
Derating factor Kv
1 (1)
@U
ln
=400Vac @U
ln
=460...480Vac
Tamb = 40°C
from AFE200
Tamb ≤ 30°C Tamb = 40°C
from aFE200
Tamb ≤ 30°C Tamb 31 ... 40°C Tamb ≤ 30°C Tamb 31 ... 40°C
1007 ... 1 MW 1 1 0.9 1 0.9 0.9 0.81
Sizes
f
sw
Switching frequency
Derating factor
Default Higher
K
t
K
alt
K
f
(4)
(2) (3)
2 kHz 4 kHz 6 kHz 8 kHz 10 kHz 12 Hz
1007 8 10, 12 0.9 1.2 1 1 1 1 0.85 0.7
1015 8 10, 12 0.9 1.2 1 1 1 1 0.85 0.7
1022 4 6, 8, 10, 12 0.9 1.2 1 1 0.85 0.7 0.55 0.4
1030 4 6, 8, 10, 12 0.9 1.2 1 1 0.85 0.7 0.55 0.4
1040 4 6, 8, 10, 12 0.9 1.2 1 1 0.85 0.7 0.6 0.5
2055 4 6, 8, 10, 12 0.9 1.2 1 1 0.85 0.7 0.6 0.5
2075 4 6, 8, 10, 12 0.9 1.2 1 1 0.85 0.7 0.6 0.5
2110 4 6, 8, 10, 12 0.9 1.2 1 1 0.85 0.7 0.6 0.5
3150 4 6, 8, 10, 12 0.9 1.2 1 1 0.85 0.7 0.6 0.5
3185 4 6, 8, 10, 12 0.9 1.2 1 1 0.85 0.7 0.6 0.5
3220 4 6, 8, 10, 12 0.9 1.2 1 1 0.85 0.7 0.6 0.5
4300 4 6, 8, 10, 12 0.9 1.2 1 1 0.85 0.7 0.6 0.5
4370 4 6, 8, 10, 12 0.9 1.2 1 1 0.85 0.7 0.6 0.5
4450 4 6, 8 0.9 1.2 1 1 0.85 0.7 0 0
5550 4 6, 8 0.9 1.2 1 1 0.85 0.7 0 0
5750 4 6, 8 0.9 1.2 1 1 0.85 0.7 0 0
5900 4 6, 8 0.9 1.2 1 1 0.85 0.7 0 0
61100 4 6, 8 0.9 1.2 1 1 0.85 0.7 0 0
61320 4 6, 8 0.9 1.2 1 1 0.85 0.7 0 0
71600 4 - 0.9 1.2 1 1 0 0 0 0
72000 4 - 0.9 1.2 1 1 0 0 0 0
72500 2 4 0.9 1.2 1 0.85 0 0 0 0
73150 2 - 0.9 1.2 1 0 0 0 0 0
73551 2 - 0.9 1.2 1 0 0 0 0 0
400 kW 4 (5) - 0.9 1.2 1 1 (5) 0 0 0 0
500 kW 2 4 (5) 0.9 1.2 1 0.85 (5) 0 0 0 0
630 kW 2 - 0.9 1.2 1 0 0 0 0 0
710 kW 2 - 0.9 1.2 1 0 0 0 0 0
900 kW 2 - 0.9 1.2 1 0 0 0 0 0
1 MW 2 - 0.9 1.2 1 0 0 0 0 0
(5) from fw 6.03.
Note! In Light Duty mode the switching frequency is set at 4 kHz for sizes up to 72000 plus size 400kW (setting
to 2kHz is possible), and is fixed at 2kHz for sizes 72500 up to 1MW (400kW excluded).
Note! If, in the Heavy duty mode, the factory setting of Switching freq mode (PAR: 568) is changed from
0=Fixed to 1=Variable, the switching frequency is controlled by the temperature of the drive heat sink
and the output frequency. For further information see the Functions and Parameters manual, menu 4.9.
