gefran ADV200 Series User Manual

ADV200 • Quick start up guide 27
Sizes
Bars: L1 - L2 - L3 - C - D - U - V - W
Recommended cable cross-section Lock screw
diameter
Tightening torque
(min)
(mm
2
) AWG / kcmil (mm) (Nm)
400kW
ADV-72000-KXX-4-MS 04 2 x 100 2 x AWG 4/0 M10
(U,V,W=M12) 25 (M10) / 45 (M12)
ADV-72000-XXX-4-SL 2 x 100 2 x AWG 4/0 M10 (U,V,W=M12) 25 (M10) / 45 (M12)
500kW
ADV-72500-KXX-4-MS 05 2 x 150 2 x kcmil 300 M10
(U,V,W=M12) 25 (M10) / 45 (M12)
ADV-72500-XXX-4-SL 2 x 150 2 x kcmil 300 M10 (U,V,W=M12) 25 (M10) / 45 (M12)
630kW
ADV-73150-KXX-4-MS 06 2 x 185 2 x kcmil 350 M10
(U,V,W=M12) 25 (M10) / 45 (M12)
ADV-73150-XXX-4-SL 2 x 185 2 x kcmil 350 M10 (U,V,W=M12) 25 (M10) / 45 (M12)
710kW
ADV-73551-KXX-4-MS 07 2 x 185 2 x kcmil 350 M10
(U,V,W=M12) 25 (M10) / 45 (M12)
ADV-73551-XXX-4-SL 2 x 185 2 x kcmil 350 M10 (U,V,W=M12) 25 (M10) / 45 (M12)
900kW
ADV-73150-KXX-4-MS 09 2 x 185 2 x kcmil 350 M10
(U,V,W=M12) 25 (M10) / 45 (M12)
ADV-73150-XXX-4-SL 2 x 185 2 x kcmil 350 M10 (U,V,W=M12) 25 (M10) / 45 (M12)
ADV-73150-XXX-4-SL 2 x 185 2 x kcmil 350 M10 (U,V,W=M12) 25 (M10) / 45 (M12)
1 MW
ADV-73551-KXX-4-MS 10 2 x 185 2 x kcmil 350 M10
(U,V,W=M12) 25 (M10) / 45 (M12)
ADV-73551-XXX-4-SL 2 x 185 2 x kcmil 350 M10 (U,V,W=M12) 25 (M10) / 45 (M12)
ADV-73551-XXX-4-SL 2 x 185 2 x kcmil 350 M10 (U,V,W=M12) 25 (M10) / 45 (M12)
Sizes
Connection
Recommended cable cross-
section
Lock screw
diameter
Recommended
terminal
Tightening
torque (min)
(mm
2
) AWG / kcmil (mm) (Nm)
400kW
ADV-72000-KXX-4-MS 04
150 300 kcmil M10 Eyelet 25
ADV-72000-XXX-4-SL
150 300 kcmil M10 Eyelet 25
500kW
ADV-72500-KXX-4-MS 05
150 300 kcmil M10 Eyelet 25
ADV-72500-XXX-4-SL
150 300 kcmil M10 Eyelet 25
630kW
ADV-73150-KXX-4-MS 06
185 350 kcmil M10 Eyelet 25
ADV-73150-XXX-4-SL
185 350 kcmil M10 Eyelet 25
710kW
ADV-73551-KXX-4-MS 07
185 350 kcmil M10 Eyelet 25
ADV-73551-XXX-4-SL
185 350 kcmil M10 Eyelet 25
900kW
ADV-73150-KXX-4-MS 09
185 350 kcmil M10 Eyelet 25
ADV-73150-XXX-4-SL
185 350 kcmil M10 Eyelet 25
ADV-73150-XXX-4-SL
185 350 kcmil M10 Eyelet 25
1 MW
ADV-73551-KXX-4-MS 10
185 350 kcmil M10 Eyelet 25
ADV-73551-XXX-4-SL
185 350 kcmil M10 Eyelet 25
ADV-73551-XXX-4-SL
185 350 kcmil M10 Eyelet 25
