ADV200 • Quick start up guide 109
tor starts the acceleration ramp and moves to the speed set in the FWD direction.
With the motor running you can adjust the speed using the PAR 602 Dig ramp
ref 2 (or PAR 604 Dig ramp ref 3, in this case modify also the selection PAR 614
Ramp ref 3 src to PAR 604 Dig ramp ref 3) and the acceleration/deceleration
ramps using Acceleration time 0 (PAR: 700) and Deceleration time 0 (PAR:
702).
To change the direction of rotation press FWD/REV.
To stop the motor with the deceleration ramp, press STOP.
If the Enable contact is opened the inverter bridge is immediately disabled and the
motor stops for inertia
To return to control using the terminal strip commands and analog speed reference:
1. Stop the motor
2. Open the Enable terminal
3. Press LOC / REM key.
Note ! For more customizations and any information that is not included in this initial customization guide, see
the description of the parameters in this manual.
