132 ADV200 • Quick start up guide
Index Error message shown
on the display
Sub-code Description
20 Param error
Condition: if an error occurs during activation of the parameter database saved in flash; the alarm
is inserted in the alarm list and alarm log.
XXX0H-X The code XXXXH-X indicates the IPA of the parameter that has been set outside the
range allowed when the database is enabled.
Solution: Set the parameter causing the error to a value within the range and run Save param-
eters. Switch the drive off and then switch it back on again.
If the IPA of the parameter is not shown in the manual, contact the service centre.
21 Encoder error
Condition: this condition may occur when the drive is powered during encoder setup each time
parameter 552 Regulation mode is set.
100H-2564 Cause: An error occurred during setup; the information received from the encoder
is not reliable. If the encoder is used for feedback the Speed fbk loss [22] alarm is
also generated.
Solution: Take the recommended action for the Speed fbk loss[22] alarm.
200H-512 Cause: The firmware on the optional encoder card is incompatible with that on the
regulation card. The information received from the encoder is not reliable
Solution: Contact Gefran in order to update the firmware on the optional encoder card.
22 Options cfg changed
Condition: this may occur when powering the drive if an expansion card has been removed or
replaced or the incorrect enable key is inserted for a given firmware function.
0064H-100 Card removed from slot 1
0014H-20 Card removed from slot 2
0003H-3 Card removed from slot 3
0078H-120 Card removed from slot 1 and from slot 2
0067H-103 Card removed from slot 1 and from slot 3
0017H-23 Card removed from slot 2 and from slot 3
007BH-123 Card removed from slot 1, from slot 2 and from slot 3
Solution: Check the hardware configuration, then press ESC. Save the parameters (Save param-
eters, menu 04.01 par 550) to save the new hardware configuration.
23
Autotune
(phasing)
0 No error
(Only Synchronous)
40
The encoder card in use cannot manage automatic phasing.
Solution: Use the appropriate encoder card
41
Incorrect Incremental encoder impulse count
Solution: Check the electric signals of the incremental encoder. Check the value of
the encoder impulse parameter
42
Incorrect absolute encoder impulse count
Solution: Check the electric signals of the absolute encoder. Check the configura-
tion of the absolute encoder
43
Incorrect incremental encoder impulse count or incorrect absolute encoder impulse
count probably caused by an incorrect value of the pole pairs parameter or a load
applied to the motor.
Solution: Check the value of the pole pairs parameter, check whether a load is
applied
44
Incorrect incremental encoder impulse count probably caused by the incorrect value
of the encoder impulse parameter.
Solution: Check the electric signals of the incremental encoder. Check the value of
the encoder impulse parameter.
45
Incorrect absolute encoder impulse count
Solution: Check the electric signals of the absolute encoder. Check the configura-
tion of the absolute encoder.
