gefran ADV200 Series User Manual

ADV200 • Quick start up guide 19
Taglia 7
Size 7
417 [16.42”]
177.8 [7.00”]
355.6 [140”]
1264
[49.76”]
1209.5
[47.62”]
Fissaggio a muro
Wall mounting
(B)
(A)
6.5
[0.26”]
6.5
[0.26”]
Ø 13
[0.51”]
19
[0.75”]
17.45
[0.69”]
15.25
[0.6”]
(A)
(B)
1407 [55.4”]
(*) Protezione in policarbonato trasparente
(*) Protective trasparent policarbonate
(*)
(*)
ADV200-...-DC
Taglia 7
Size 7
417 [16.42”]
177.8 [7.00”]
355.6 [140”]
1264
[49.76”]
1209.5
[47.62”]
(A)
(B)
(B)(A)
7.25
[0.29”]
5.5
[0.21”]
5.5 [0.21”]
15
[0.59”]
Ø
10 [0.39”]
11.25
[0.44”]
6.5 [0.26”]
Ø
13
[0.51”]
19
[0.75”]
6.5 [0.26”]
12.5 [0.49”]
12
[0.47”]
Taglie 1-2-3
Sizes 1-2-3
Taglia 4
Size 4
(B)(A)
Taglia 5
Size 5
(B)(A)
6.5
[0.26”]
19
[0.75”]
Ø
13
[0.51”]
6.5 [0.26”]
12
[0.47”]
12.75 [0.50”]
(B)(A)
Taglia 6
Size 6
6.5 [0.26”]
6.5 [0.26”]
Ø
13
[0.51”]
19
[0.75”]
24.95 [0.98”]
12
[0.47”]
Recommended screws for fastening
Size 1 (ADV 1...) Size 2 (ADV 2...) Size 3 (ADV 3...) 4 x M5 x 12 mm screws + Grover (spring-lock) washer + Flat washer
Size 4 (ADV 4...) Size 5 (ADV 5...) 4 x M6 x 16 mm screws + Grover (spring-lock) washer + Flat washer
Size 6 (ADV 6...) 5 x M6 x 16 mm screws + Grover (spring-lock) washer + Flat washer
Size 7 (ADV 7...) 6 x M6 x 16 mm screws + Grover (spring-lock) washer + Flat washer
Note! Other dimensions see chapter “9.10 Weight and dimensions”, page 147.
