ADV200 • Quick start up guide 57
Sizes
Technical data of the Internal Braking Units (Duty 50%)
Nominal current of the
internal braking unit
I
rms
(A)
Peak current
I
pk
(A)
Minimum braking
resistance value
R
br (
)
1007
Internal Braking Units
(standard internal)
5.7 8 100
1015 5.7 8 100
1022 5.7 8 100
1030 5.7 8 100
1040 5.7 8 100
2055 8.5 12 67
2075 8.5 12 67
2110 15.5 22 36
3150 22 31 26
3185 37 53 15
3220 37 53 15
4300
Internal Braking Units
(standard internal)
57 80 10
4370 57 80 10
4450 76 107 7.5
5550 76 107 7.5
≥ 5750 and
ADV200-...-DC
External Braking Unit
(optional)
See BUy manual for all technical details.
BUy-1020 28 40 17
BUy-1050 70 100 6.8
BUy-1085 120 170 4
