gefran ADV200 Series User Manual

ADV200 • Quick start up guide 89
Step 1 - Connections
For ADV-...-4-DC versions please refer to the diagrams in paragraph “5.1.6 Power
line connection”, page 33 and “5.1.8 Motor connection”, page 37.
Connect the drive to the power supply as illustrated in the following diagrams:
Connection to the mains and motor
L1 L2 L3 BR1 BR2 CDUVW
K1M
L1 L2 L3
F1
(3ph-400 V/460 V 50/60 Hz)
AC AC
,
M
3ph
Connection of the drive enabling contact
R21R24 56C1 78910 11 12 C2 C3 S3
R11R14 123
4
S1+S1- 13 14 IS1IC1
IC2
IS2
Enable
Connection of the drive enabling contact with Safety function
(SIL2 conguration)
R21R24 56C1 78910 11 12 C2 C3 S3
R11R14 123
4
S1+S1- 13 14 IS1IC1
IC2
IS2
Enable
54321
Strip T2 (Regulation terminals)Safety Input / Output connector
Strip T1 (Regulation terminals)
