gefran VDI100 Series User Manual

00-27 HD/ND Mode selection 0: HD
11-01 Carrier frequency 5.0kHz
05-01 Frequency setting of speed-stage 0 6.0 Hz
05-02 Frequency setting of speed-stage 1 30.0 Hz
05-03 Frequency setting of speed-stage 2 60.0 Hz
03-04 Multi-function terminal Function setting-S5 2: Multi-speed/position setting command 1
03-05 Multi-function terminal Function setting-S6 3: Multi-speed/position setting command 2
03-28 Photo-coupler output 23: Source of operation command
08-00 Stall prevention function
xx1x : Stall prevention ineffective in deceler-
ation
08-09 Selection of input phase loss protection 1: Enable
08-10 Selection of output phase loss protection 1: Enable
Code Parameter Name / Range
00-30 Modified Parameters
0: Disable
1: Enable
This parameter automatically lists all the adjusted parameters. When the default value is adjusted and 00-33=1,
it will list all the parameters different from default values in the advanced modes and these parameters can be
edited directly. The adjusted parameters list displays only when 00-33 is set from 0 to 1 or 00-33=1 at start up.
If user wants to restore to the original editing interface, it is only required to set parameter 00-33=0.
This function can display 250 adjusted parameters. If they are more than 250 parameters, it will list the adjust-
ed parameters before 250.
Note: It is only for LCD keypad.
Example:Set00-03(alternativeruncommandsourceselection)tobedifferentfromthedefaultvalue.
Steps LCD Display Descriptions
1
Group
00 Basic Func.
01 V/f Pattern
02 Motor Parameter
The starting parameter group (00) in the setting modes of ▲ (Up)/ ▼ (Down) selection
groups.
2
PARA 00
-01. Motor Direction
-02. RUN Source
-03. Sub RUN Source
Press READ/ ENTER key and ▲ (Up)/ ▼ (Down) to select alternative run command source
(00-03).
3
Edit 00-00
Sub RUN Source
1 Terminal
(0 ~4)
<2>
Press READ/ ENTER key and adjust the value. The selected setting value will flash.
4
PARA 00
-33. Modify parameter
-41. User P1
-42. User P2
Press DSP/ FUN to the menu of modified parameters (00-33).
5
Edit 00-33
Modify parameter
1 Enable
(0 ~1)
<0>
Press READ/ ENTER key to adjust the value to 1 (The modified parameter is enabled.) The
selected setting value will flash.
6
Modify 00
00-03. Sub RUN Source
00-33. Modify parameter
Press DSP/ FUN back to the advanced modes.
Userparametersetting(00-41to00-56)(onlyforLCDkeypad)
00- 41 User parameter 0
00- 42 User parameter 1
00- 43 User parameter 2
108 VDI100 • Instruction manual
