gefran VDI100 Series User Manual

00- 44 User parameter 3
00- 45 User parameter 4
00- 46 User parameter 5
00- 47 User parameter 6
00- 48 User parameter 7
00- 48 User parameter 8
00- 50 User parameter 9
00- 51 User parameter 10
00- 52 User parameter 11
00- 53 User parameter 12
00- 54 User parameter 13
00- 55 User parameter 14
00- 56 User parameter 15
• User parameter (00-41 ~ 00-56) can select 16 sets of parameters (01-00 group ~ 24-06 group) and put
them into the list to do the fast access setting.
• When the access setting of parameter 13-06 is set to 1, user parameter 00-41 ~ 00-56 can be displayed
and changed.
• User parameter 00-41 ~ 00-56 can be changed in the advanced modes, exclusive of being in operation.
• Set value in the parameter of 00-41 ~ 00-56 and set 13-06 to 1.
• When 13-06=1, only parameter of 00-00 ~ 00-56 can be set or read in the advanced modes. 13-06=1 is
enabled in the parameter setting of 00-41~00-56.
• When user would like to leave the screen of user parameters, press RESET key and then DSP/FUN key to
select parameter Group 13.
Example:Set00-03(alternativeruncommandsourceselection)tobedifferentfromthedefaultvalue.
Steps LCD Display Descriptions
1
Group
00 Basic Func.
01 V/f Pattern
02 Motor Parameter
The starting parameter group (00) in the setting modes of ▲ (Up)/ ▼ (Down) selection
groups.
2
PARA 00
-41. User P0
-42. User P1
-43. User P2
Press READ/ ENTER key and ▲ (Up)/ ▼ (Down) to select user parameter 0 (00-41).
3
Edit 00-00
User P0=00-41
00-41 User P0
<00-01 - 24-07>
Press (READ/ ENTER) key to the screen of data setting/ read.
* The selected setting value will flash.
4
Edit 00-00
User P0=00-41
03-00 S1 Function Sel
<00-01 - 24-07>
Press ◄ (Left) / ►(Right) and ▲(Up) / ▼(Down) key to set the value to 03-00 ( Multi-fun-
ction terminal Function Setting-S1)
5
Edit 00-00
User P0=00-03
03-00 S1 Function Sel
<00-01 - 24-07>
Press (READ/ ENTER) key to save 03-00 and the digit stops flashing and the screen displays
User P0 = 03-00; 03-00
(Multi-function terminal Function Setting-S1) has been defined as 00-41. Few seconds later,
the selected digit will flash again.
6
Edit 00-00
Freq Ref
12-16=000.00Hz
----------------------------------
12-17=000.00Hz
12-18=0000.0A
Press (DSP/ FUN) key to the display of main screen.
* If users do not press BACK key in one minute, the screen will automatically display the moni-
tor mode shown as the left figure. The automatically return time can be set via 16-06
VDI100 • Instruction manual 109
