gefran VDI100 Series User Manual

Value
Function
Description
Control mode
Name LCD Display V/f
V/f
+PG
SLV SV
PM
SV
PM
SLV
SLV2
40
Switching between motor 1/
motor 2
Motor 2 Switch ON: Start motor 2 O O O O O O O
41 PID Sleep PID Sleep ON: PID Sleep O O O O O O O
42 PG disabled PG disabled ON: Speed control without PG X O X X X X X
43 PG integral reset I-Time Reset
ON: Integral value reset of
speed control with PG
X O X O O X X
44
Mode switching between
speed and torque
Speed/Torque change ON: Torque control mode X X X O O X X
45 Negative torque command Reverse Tref
ON: Reverse external torque
command
X X X O O X X
46 Zero-servo command Zero-Servo ON: Zero-servo operation X X X O O X X
47 Fire Mode Fire Mode
ON: Turn off hardware and
software fault or alarm
protection and run the inverter
with value of 01-02 (a special
application of HVAC)
O O O O O O O
48 KEB acceleration KEB Accel. ON: KEB acceleration start O O X X X X O
49 Parameters writing allowable Write Enabled
ON: all parameters are
writable
OFF: Except reference frequen-
cy (00-05) all parameters are
write-protected.
O O O O O O O
50
Unattended Start Protection
(USP)
USP
ON: After power is input, the
inverter ignores the operation
command
OFF: After power is input,
the inverter will return the
operation status before power
is cut off.
O O O O O O O
51
Mode switching between
speed and position
Multi Pos. Switch
ON: Switch to position mode
OFF: Switch to speed mode
X X X O O X X
52
Multi Position Reference
Enable
Multi Pos. Enable
ON: Position reference is
enabled.
OFF: Position reference is
disabled.
X X X O O X X
53
2-Wire Self Holding Mode
(Stop Command)
2-Wire (STOP)
2-Wire Self Holding Mode (
ON: Stop Command).
O O O O O O O
54 Reserved Reserved Reserved - - - - - - -
55 Reserved Reserved Reserved - - - - - - -
56 Reserved Reserved Reserved - - - - - - -
57 Reserved Reserved Reserved - - - - - - -
58 Safety Function
Safety Function
ON: Stop by the setting of
08-30
O O O O O O O
59 Reserved Reserved Reserved - - - - - - -
60 Reserved Reserved Reserved - - - - - - -
61 Reserved Reserved Reserved - - - - - - -
62 EPS function EPS Input ON:EPS input X X X O O X X
63 Reserved Reserved Reserved - - - - - - -
64 Reserved Reserved Reserved - - - - - - -
65 Short-circuit braking SC Brk ON: SC Brk turn on X X X X X O X
03-0X =00 2-wire control: forward operation
03-0X =01 2-wire control: reverse operation. Refer to the 2-wire operation mode in Figure 4.4.1.
03-0X =02 Multi-speed/position setting command 1.
03-0X =03 Multi-speed/position setting command 2.
03-0X =04 Multi-speed/position setting command 3.
VDI100 • Instruction manual 145
