08-25=0: When the inverter is supplied by power, detection external fault function will execute.
08-25=1: When the inverter is start to run, detection external fault function will execute.
Code Parameter Name / Range
08-30
Digital Input Stop Command Selection
0: Deceleration to Stop
1: Coast to Stop
When 03-00~03-07=58,the inverter will stop by the set of 08-30.
Code Parameter Name / Range
08-37 Fan Control Function
0: Start in operation
1: Permanent Start
2: Start in high temperature (except of the models of
6750 or the above)
08-38 Delay Time of Fan Off
0~600 sec
08-37=0: The inverter start to run and the fan will follow to run. If the inverter stop and the time is longer than
the value of 08-38, the fan stop. If the temperature for heat sink is higher than the temperature of inside-detec-
tion and the inverter doesn’t run, the fan will start run automatically.
08-37=1: The inverter is supplied by power, the fan start to run.
08-37=2: The temperature for heat sink is higher than the temperature of inside-detection, the fan start to run.
After The temperature for heat sink is lower than the temperature of inside-detection and the time is over 08-38,
the fan stop.
Note : There is no 08-37=2 for the models of 6750 or the above.
Code Parameter Name / Range
08-35 Motor Overheat Fault Selection
0: Disable
1: Deceleration to Stop
2: Free Run to top
3: Continue Running
08-36 PTC Input Filter Time Constant
0.00 ~ 10.00 sec
08-39 Delay Time of Motor Overheat Protection
0~300 sec
08-42 PTC Protection Level
0~10.0V
08-43 PTC Restart Level
0~10.0V
08-44 PTC Warning Level
0~10.0V
Motor Overheat Fault Selection
It execute motor overheat protection by the resistor (PTC) that built-in the motor. The resistor (PTC) is between
AI2 and GND and a divided resistor R ,as the pic 4.3.65(b)
08-35=0: Motor overheats fault function is off.
08-35=1: When the motor is overheating, it decelerates to stop.
08-35=2: When the motor is overheating, it free runs to stop.
08-35=3: When the motor is overheating, it does not stop running until reach the value of 08-42.
VDI100 • Instruction manual 209
