Group 10: PID Parameters
Code Parameter Name Setting Range Default Unit
Control mode
Attribute
V/f
V/f
+PG
SLV SV
PM
SV
PM
SLV
SLV2
10-13
PID Feedback Loss Det.
Time
0.0~10.0 1.0 s O O O O O O O
10-14 PID Integral Limit 0.0~100.0 100.0 % O O O O O O O *1
10-15
~
10-16
Reserved
10-17
*Start Frequency of PID
Sleep
0.00~599.00 0.00 Hz O O O O O O O
10-18 Delay Time of PID Sleep 0.0~255.5 0.0 s O O O O O O O
10-19
*Frequency of PID Waking
up
0.00~599.00 0.00 Hz O O O O O O O
10-20
Delay Time of PID Waking
up
0.0~255.5 0.0 s O O O O O O O
10-21
~
10-22
Reserved
10-23
PID Output Limit 0.00~100.0 100.0 % O O O O O O O *1
10-24 PID Output Gain 0.0~25.0 1.0 - O O O O O O O
10-25
PID Reversal Output
Selection
0: No Allowing Reversal Output
0 - O O O O O O O
1: Allow Reversal Output
10-26
PID Target Acceleration/
Deceleration Time
0.0~25.5 0.0 s O O O O O O O
10-27 PID Feedback Display Bias -99.99~99.99 0.00 - O O O O O O O
10-28 PID Feedback Display Gain 0.00~100.00 100.00 - O O O O O O O
10-29 PID Sleep Selection 0: Disable 1 - O O O O O O O
1: Enable
2: set by DI
10-30 Upper Limit of PID Target 0.0 ~ 100.0 100.0 % O O O O O O O
10-31 Lower Limit of PID Target 0.0 ~ 100.0 0.0 % O O O O O O O
10-32 Reserved
10-33
Maximum Value of PID
Feedback
1 ~ 10000 999 - O O O O O O O
10-34 PID Decimal Width 0 ~ 4 1 O O O O O O O
10-35 PID Unit 0: % 0 O O O O O O O *7
1: FPM
2: CFM
3: SPI
4: GPH
5: GPM
6: IN
7: FT
8: /s
9: /m
10: /h
11: °F
12: inW
13: HP
14: m/s
15: MPM
16: CMM
17: W
18: kW
19: m
20: °C
21: rpm
22: Bar
23: Pa
VDI100 • Instruction manual 75
