gefran VDI100 Series User Manual

Group 17: Automatic Tuning Parameters
Code Parameter Name Setting Range Default Unit
Control mode
Attribute
V/f
V/f
+PG
SLV SV
PM
SV
PM
SLV
SLV2
17-00
Mode Selection of Automa-
tic Tuning*
0: Rotation Auto-tuning
VF:2
VF+PG:2
SLV:6
SV:6
SLV2:6
- O O O O X X O
1: Static Auto-tuning
2: Stator Resistance Measurement
3: Reserved
4: Loop Tuning
5: Rotation Auto-tuning Combination
(item: 4+2+0)
6: Static Auto-tuning Combination (item:
4+2+1)
17-01 Motor Rated Output Power 0.00~600.00 kVA kW O O O O X X O
17-02 Motor Rated Current 0.1~1200.0 kVA A O O O O X X O
17-03 Motor Rated Voltage
230V: 50.0~240.0 220 V O O O O X X O
400V: 100.0~480.0 440
17-04 Motor Rated Frequency 5.0~599.0 60.0 Hz O O O O X X O
17-05 Motor Rated Speed 0~24000 kVA rpm O O O O X X O
17-06 Pole Number of Motor 2~16 (Even) 4 Pole O O O O X X O
17-07 PG Pulse Number 0~60000 1024 ppr O O O O X X O
17-08 Motor no-load Voltage 230V: 50~240 - V O O O O X X O
400V: 100~480
17-09 Motor Excitation Current 0.01~600.00 - A X X O O X X X
17-10 Automatic Tuning Start
0: Disable
1: Enable
0 - O O O O X X O
17-11
Error History of Automatic
Tuning
0: No error 0 - O O O O X X O
1: Motor data error
2: Stator resistance tuning error
3: Leakage induction tuning error
4: Rotor resistance tuning error
5: Mutual induction tuning error
6: Encoder error
7: DT Error
8: Motor’s acceleration error
9: Warning
17-12
Proportion of Motor Leaka-
ge Inductance
0.1~15.0 3.4 % X X O O X X X
17-13 Motor Slip Frequency 0.10~20.00
1.78** Hz X X O O X X X
17-14
Selection of Rotation
Auto-tuning
0: VF Rotation Auto-tuning 0 - O O O O X X O
1: Vector Rotation Auto-tuning
kVA: The default value of this parameter will be changed by different capacities of inverter.
*: The default value is 1 in VF/ VF+PG mode while the default value is 0 in SLV/ SV/ SLV2 mode.
*: It is suggested that HD/ ND mode (00-27) and application presets (00-32) be selected first before motor performs auto-tuning.
Note: The value of mode selection of automatic tuning is 6 (Static Auto-tuning Combination). When do auto-tuning with no-load motor, it suggest select 17-00=5 (Rotation
Auto-tuning Combination)
** Displayed when 17-00=2
Group 18: Slip Compensation Parameters
Code Parameter Name Setting Range Default Unit
Control mode
Attribute
V/f
V/f
+PG
SLV SV
PM
SV
PM
SLV
SLV2
18-00
Slip Compensation Gain at
Low Speed.
0.00~2.50 VF:0.00 - O X O O X X O *1
SLV*
18-01
Slip Compensation Gain at
High Speed.
-1.00~1.00 0.0 - O X O X X X X *1
18-02 Slip Compensation Limit 0~250 200 % O X X X X X X
VDI100 • Instruction manual 87
