General Dynamics URC-200 (V2) User Manual

General Dynamics C4 Systems URC-200 (V2)
4
Transmitter Characteristics
High Power
Output Mode
Tolerance Expressed in
Watts Avg.
Expressed in
dBm Avg.
Expressed
in Watts
CW
Expressed in
dBm CW
AM (at 80%
AM PT ±5%)
Maximum (+2
dBm)
15.85 Watts
42 dBm
12.01
Watts
40.8 dBm
Typical
10 Watts
40 dBm
7.58 Watts
38.8 dBm
Minimum (-2
dBm)
6.31 Watts
38 dBm
4.78 Watts 36.8 dBm
Low Power
Output Mode
Tolerance Expressed in
Watts Avg.
Expressed in
dBm Avg.
Expressed
in Watts
CW
Expressed in
dBm CW
AM (at 80%
AM PT ±5%)
Maximum (+2
dBm)
7.94 Watts
39 dBm
6.02 Watts 37.8 dBm
Typical
5 Watts
37 dBm
3.79 Watts
35.8 dBm
Minimum (-2
dBm)
3.16 Watts
35 dBm
2.39 Watts 33.8 dBm
High Power
Output Mode
Tolerance Expressed in Watts Expressed in
dBm
FM
Maximum (+2 dBm)
15.85 Watts
42 dBm
Typical
10 Watts
40 dBm
Minimum (-2 dBm)
6.31 Watts
38 dBm
Medium Power
Output Mode
Tolerance Expressed in Watts Expressed in
dBm
FM
Maximum (+2 dBm)
7.94 Watts
39 dBm
Typical
5 Watts
37 dBm
Minimum (-2 dBm)
3.16 Watts
35 dBm
Low Power
Output Mode
Tolerance Expressed in Watts Expressed in
dBm
FM
Nominal
0.1 Watts or 100 mW
20 dBm
Modulation
AM (PT)
60% to 90% at 1 kHz. : 15% Max. @ 80% AM
AM (CT)
70% nominal at 8 kHz. : Distortion 15% Max. @ 70% AM
FM (PT)
VHF
±
3.3 kHz at 1 kHz. : Distortion 10% Max.
UHF
±6.5 kHz at 1 kHz. : Distortion 10% Max.

General Dynamics URC-200 (V2) Specifications

General

Brand	General Dynamics
Model	URC-200 (V2)
Category	Transceiver
Language	English
