General Dynamics C4 Systems URC-200 (V2)
82
e. Move the cursor to Modulation Type and press the "AM" soft key.
f. Move the cursor to the Generate Frequency position and enter 115.000 from the R2600
keypad.
g. Move the cursor to Modulation Type and press the "AM" soft key.
h. Move the cursor to bandwidth and press the "NARROW ±5 kHz" soft key.
i. Move the cursor to the Duplex Offset position and press the "DON'T CARE" soft key.
j. Move the cursor to Synth. Format Sel (synthesizer format select) and select the "Tone A"
soft key.
k. Move the cursor to Freq (frequency) and enter 01000.0 from the keypad.
l. Move the cursor to the DTMF Code position and press the "DON'T CARE" soft key.
NOTE
The “more” soft key may have to be depressed for the “DON”T CARE” soft
key to be displayed.
m. Press the "return" soft key. Repeat steps A through K for presets 02 through 10. Use
Table 22 to program the frequency presets in steps D and E above.
n. Press the "return" soft key.
Table 22 - AM Frequency Presets
Preset
Frequency
URC-200 (V2)
R2600
MHz
CH1
CH01
115.000
CH2
CH02
133.025
CH3
CH03
149.975
CH4
CH04
225.075
CH5
CH05
275.000
CH6
CH06
299.975
CH7
CH07
300.000
CH8
CH08
312.000
CH9
CH09
355.000
CH0
CH10
399.975
4. Perform the following steps to complete the setup on the R2600 analyzer.
a. Press RF key on the R2600 panel. Move the cursor to RF Control and press the "GEN"
soft key.
b. Move the cursor to the Output Lvl (RF Output Level) position and enter a level of -050.0
dBm from the keypad.
c. Move the cursor to the Gen RF Out position and press the "RF IN/OUT" soft key.
d. Depress the AUD (Audio) key on the R2600 panel. Move the cursor to the Synth
(Synthesizer) position and enter 30% from the keypad.
