General Dynamics C4 Systems URC-200 (V2)
7
1.3.2.1 Transceiver - URC-200 (V2)
The transceiver is contained in cast-aluminum housing with all operating controls and connectors
located on the front panel. The battery connectors, for two batteries, are located on the rear panel.
The front panel components are protected by handles on the sides, and an extension on the top
cover protects the volume and squelch controls.
1.3.2.2 Antenna - UVU-100
CAUTION
To comply with RF exposure requirements, a minimum separation distance of
20 cm (7.9 inches) is required between the antenna and all persons while the
transceiver is transmitting. ManPack (backpack) and hand-carry users should
not exceed 50% duty cycle, as this approaches RF hazard limits and reduces
battery life.
The antenna is a 12-inch long, broadband, VHF/UHF vertically polarized antenna that is attached to
the front panel antenna connector. The antenna connector is a BNC type connector, surrounded by
a threaded sleeve. The antenna is screwed onto this sleeve.
1.3.2.3 Battery Case - UBC-100
The battery case holds two batteries. When replacing batteries, always use two of the same part
number. When replacing non-rechargeable batteries, always replace both. Refer to Table 2 for
compatible battery types, part numbers, and reference documents.
Table 2 - Battery Types
Dioxide
Dioxide
