General Dynamics C4 Systems URC-200 (V2)
121
* Storage temperature does not include the front panel
display. The display is rated for storage
at -40°C to +70°C.
5.8 Electrical Interfaces
Figure 11 shows interface connector locations for the URC-200 (V2). The following tables list the
interface characteristics of the voltages and signals of the URC-200 (V2) power, HDST, and
Remote connectors, respectively. Connector reference designation and connector part numbers are
given in each table title. Table 29 provides part identification data for each connector.
Table 25 - Power Connector J1 (CA110821-1) Pin Characteristics
PIN FUNCTION
1
12V Battery 1 - Negative / Transceiver Ground for External Power Source
2
12V Battery 2 - Negative (Tied to Pin 4 internal to the Transceiver)
3
Rechargeable battery sense. No connection for non-rechargeable battery.
Grounded for rechargeable battery.
4
12V Battery 1 - Positive (Tied to Pin 2 internal to the Transceiver)
5
12V Battery 2 - Positive / +24 V transceiver power from External Power
Source
6 No Connection
