General Dynamics C4 Systems URC-200 (V2)
120
Table 24 - Error Messages
Display Error Title Description
Err – bEAC Beacon Lock Failure This message indicates that there is no
synthesizer lock on beacon.
Err – EEPr EEprom Failure This message indicates that data could not be
written into the EEPROM and that the
processor should be replaced.
Err – FACt Factory Init Incomplete This message is produced after the
installation of a newly programmed
microprocessor. It indicates that the
initialization has not been completed for this
transceiver.
Err – noSC Scan Error This message indicates that an attempt to
begin scanning failed because less than two
channels are selected for Scan mode.
Err – trPr PA Path Over This message indicates that the VFWD is
below the calculated threshold value.
Err – UOLt Voltage Out of Range This message indicates that the 70 volt
supply is out of its normal range either high
(>80 V) or low (<60 V).
tOO – HOt Over Temp Error This message indicates that the transmitter’s
power amplifier temperature is above normal
range. When this alarm condition exists, the
transceiver will automatically reduce the
transmitter power by 15 dB until the
temperature returns to normal range.
5.6 Shipping
Use the original shipping container and packing material to re-pack the hardware for shipping. To
pack the hardware, re-use the protective packing material. Tape container closed with strapping or
package tape. If the original packing materials are not available, pack hardware in a cardboard
container surrounded on all sides by rigid foam so it does not shift in the container. Tape container
closed with strapping or package tape.
5.7 Storage
Parameter
Specification
Storage temperature
-50°C to +70°C*
Humidity
95% non-condensing
Altitude
50,000 ft., non-operating
